I just tried matplotlib-0.54 under Win98 with the GTKAgg backend and it crashes python when I do

import matplotlib.matlab

It doesn't seem to get far enough to generate any helpful diagnostics I'm afraid.

I've reverted to 0.53.1 for the moment.

Anyone else had success or failure in Win98?

Gary

## ···

----- Original Message -----

From: John Hunter <jdhunter@...4...>

Date: Thu, 20 May 2004 09:03:47 -0500

To: matplotlib-users@lists.sourceforge.net

Subject: [Matplotlib-users] ANN matplotlib-0.54

## What's new in matplotlib 0.54

I've done a lot of rewriting of the core of matplotlib to support some

new features - mainly fast handling of polygon collections (pcolor and

scatter) and since the changes were pervasive, I took to opportunity

to fix some things that were bugging me about the design of

matplotlib. If you use the API, creating your own Axes, Subplots,

Lines, Rectangles, Texts, or working directly with transforms and

bboxes, you will need to upgrade your code, since the constructors of

all these objects have been simplified. The major changes affecting

users of the matlab interface are for pcolor and scatter. These

changes and others are detailed below and in

http://matplotlib.sf.net/API_CHANGES. Sorry for the pain - in the

long run, the new design is much cleaner and easier to work with, and

as far as I can see, will be stable.More general transformation architecture

----------------------------------------Earlier versions of matplotlib handled transformation of x and y

separately (ie we assumed all transformations were separable) but this

makes is difficult to do rotations or polar transformations, for

example. The new transformation lays the framework for doing general

transformations; see the transforms module

http://matplotlib.sf.net/matplotlib.transforms.html.More efficient pcolor

---------------------pcolor is now implemented with matplotlib.collections. polygon

collections which should provide significantly faster performance

across backends. The return value from pcolor is now a PolyColleciton

object rather than a list of patches, but the API is largely

compatible. See http://matplotlib.sf.net/API_CHANGES. The old function

pcolor_classic is retained for full backward compatibility.New scatter plots

-----------------The http://matplotlib.sf.net/matplotlib.matlab.html#-scatter command

is rewritten, and is implemented in the backend with a new polygon

collection class. For large scatter plots, the performance is 5 times

faster across all backends and 10 times faster for the *Agg

backends. Also, scatter works with many symbols: diamonds, sqaures,

oriented triangles, circles and more. As with pcolor, the scatter

command returns a collection instance rather than a list of patches as

before; see See http://matplotlib.sf.net/API_CHANGESAlso the size argument is now in points^2 (the area of the symbol in

points) and is not in data coords as before. This fixes a few

problems: symbols are not skewed by unequally shaped axes, scatter

works with log coords w/o distoring the symbol, and it is matlab

compatible.The function scatter_classic is the old scatter function and will work

identically.Enhanced mathtext

-----------------A significant rewrite of the mathtext module provides much more

precise layout. The freetype component has been factored out of the

layout engine and replaced by an abstract class for font

handling. This lays the groundwork for ps mathtext. The text clipping

problems have been fixed. Added spacing commands '\/' (small space)

and '\ ' (regular space), and '\hspace{frac}' (space is fraction of

pointsize) as well as composite chars such as \angstrom. Fixed

over/under subscripts so you can say x_i^j and nested subscripts if

you do x_i_{j} (you need the curlys)Many new plot symbols and markers

---------------------------------Thanks Gary Ruben. See

http://matplotlib.sf.net/matplotlib.matlab.html#-plotFont cacheing

-------------Paul Barrett added caching support to the font manager to increase

performance. This and other changes have dramatically improved

postscript backend performance.Newlines in text

----------------After much encouragement from Al, I finally got around to supporting

newline separated text in the Text frontend, so this is no longer

backend dependent. As a bonus, it even works with arbitrary

rotations. There is an additional text attribute 'multialignment' that

specifies the alignment of the lines in multiline text. See

http://matplotlib.sf.net/examples/multiline.py and

http://matplotlib.sf.net/screenshots.html#align_text. Works with all

text instances except mathtext.Axes hold

---------matlab compatible hold command determines whether subsequent plot

commands overlay current plot or clear the axes by default. Default

setting is set in matplotlibrc and toggled by the hold command.New rc file options

-------------------You can control grid properties and tick padding (the space between

the axes and tick label) in matplotlibrc. The new options and defaults

areaxes.hold : True # whether to clear the axes by default on

# each plot command. Toggle with hold command

grid.color : k # grid color

grid.linestyle : : # dotted

grid.linewidth : 0.5 # in pointstick.major.pad : 4 # distance to major tick label in points

tick.minor.pad : 4 # distance to the minor tick label in pointsFull dash control

-----------------You can precisely control the dashes with a sequence of on off ink in

points. See http://matplotlib.sf.net/examples/dash_control.pyRemoved close buttons from GUI

------------------------------Steve Chaplin persuasively argued these were a bad idea. It's taken me

a while not to instinctively try and click on the missing buttons, but

I'm used to it now.Properly aligned text with arbitrary alignments

-----------------------------------------------You can now expect horizontal and vertical alignment specifications to

work with text at an arbitrary angle, eg, 45 degrees. See

http://matplotlib.sf.net/examples/alignment_test.pyAdded stem plotting command

---------------------------See http://matplotlib.sf.net/matplotlib.matlab.html#-stem and

http://matplotlib.sf.net/examples/stem_plot.pyBug fix roundup

---------------Executive summary: fixed ps centering, errorbar autoscaling, constant

data plot, copy tick attribute, mathtext fontsizing in interactive

mode, missing draw if interactive, some numerix/numarray

incompatibilities in type handling, agg memory leak, wx tooltips and

close not returning interpreter.See http://matplotlib.sf.net/CHANGELOG for details.

Downloads at http://sourceforge.net/projects/matplotlib

-------------------------------------------------------
